Overview
The SANFA CHP-160S Co2 incubator is a professional instrument specially designed for cell, tissue and bacterial fostering. It uses Water-jacketed Heating mode, has a volume of 160L, and has intelligent control functions. It is suitable for microbiology, medical research and other fields.
Features
1. Microcomputer intelligent controller with temperature control, CO2 gas, door temperature, water level, UV Lamp, timing control and over temperature, water level, Safety protection, alarm function
2. The CO2 inlet is equipped with a microbial effective Filter, with a filtrating efficiency of up to 99.99%, which effectively filtrates bacteria and dust particles (optional)
3. The ultraviolet sterilization lamp is located on the back wall of the box, which can be regularly disinfected to kill the floating bacteria in the circulating air and the water vapor of the humidifying disc to prevent pollution
4. Glass door can be heated to prevent condensation and microbial contamination
5. Using antibacterial stainless steel liner, the four corners of the cavity arc design, easy to clean, adjustable shelf
6. Upgraded touch color screen intelligent temperature control instrument supports programmable, display operation Linear dispersion, view temperature, Humidity, CO2 concentration Linear dispersion and abnormal alarm, temperature control is more accurate, CO2 concentration is more stable
7. Can be equipped with RS-485 interface, connect printer and computer to record parameter changes (optional)
Principle
Co2 incubator precisely adjusts the temperature, CO2 concentration and Humidity in the box through intelligent controller, adopts natural evaporation Humidification mode, CO2 intake is equipped with high-efficiency Filter, UV Lamp regularly sterilizes, box door heating prevents condensation, and ensures a stable and sterile foster environment.
Applications
Microbiology, agricultural science, medicine, fostering of various tissues and cells, AIDS research, tumor research, heart disease research, virus propagation, bacterial fostering, genetic engineering, testtube babies, cloning technology, immunology
Steps
1. Connect the power supply to ensure that the working Ambient Temperature is within the range of + 5~ 35 ℃
2. Temperature range (RT + 5~ 60 ℃) and CO2 control range (0~ 20%)
3. Optional CO2 Filter and RS-485 Interface
4. Start the UV Lamp for regular disinfection
5. Monitor Temperature, CO2 concentration and Humidity Linear dispersion, handle abnormal alarms
6. Clean liners and shelves after use
Notice
• Power supply voltage is 220V 50Hz to avoid over-range use
• Regularly check the CO2 Intake Filter to prevent clogging
• Pay attention to safety when using UV Lamps and avoid direct exposure
• The heating function of the box door needs to be kept open to prevent condensation from forming
• Ambient Temperature needs to be within + 5~ 35 ℃, exceeding may affect performance
• Use proper tools when cleaning to avoid damage to the antibacterial stainless steel liner
• Monitor the alarm function to deal with excessive temperature or abnormal water level in a timely manner
