Overview
SANFA ZHP-Y2112L double-decked thermostatic Shaker is an intelligent device that integrates thermostatic foster and oscillation. It is widely used in bacterial foster, fermentation, hybridization, biochemical reaction and enzyme and cell tissue research that require temperature and Oscillation Frequency. It can perform motion and static foster on microbial cells and various strains.
Features
1. Set thermostatic foster and oscillation in one machine dual-use.
2. Microcomputer Control Temperature and Oscillation Frequency, With Timing Function, LCD Display Display Temperature and Frequency in Real Time, With Over Temperature, Power Outage, Leakage, Sensor Fault Alarm Functions.
3. The Compressor and circulating fan use imported products, environmentally friendly and fluorine-free refrigeration.
4. AC brushless motor, long life, wide speed regulation, constant torque, constant Rotation speed, maintenance-free.
5. Concept aesthetic design, with observation window, liner and Shaker Table are made of antibacterial stainless steel, four corners arc for easy cleaning.
6. Equipped with a door switch, the oscillation system stops working when the box door is opened, and automatically starts when it is closed.
7. Rotation speed circuit is reasonably controlled to ensure that the Shaker starts slowly and accelerates smoothly to prevent liquid splashing.
8. Independent temperature limit alarm system, automatically cut off the power supply when the temperature exceeds the limit (optional).
9. Upgraded large-screen LCD display, more accurate temperature control, smoother Oscillation Frequency, can be equipped with RS-485 interface to connect printers and computers (optional).
Principle
The device precisely adjusts the temperature and Oscillation Frequency through a microcomputer Control system, adopts a gyroscopic oscillation method, and combines environmentally friendly fluorine-free refrigeration technology to foster stable oscillation in a thermostatic environment. When the box door is opened, the oscillation system automatically stops working to ensure safety.
Applications
Bacterial fostering, fermentation, hybridization, biochemical reactions, enzyme and cell tissue research, microbial cell and strain fostering
Steps
1. Connect the power supply (~ 220V 50Hz).
2. Set the required temperature (RT + 5~ 65 ℃) and Oscillation Frequency (30~ 300rpm).
3. Set the Timer Range (1~ 9999min) as needed.
4. Place the sample on the tray and close the box door to start the oscillation system.
5. Monitor operating parameters through the LCD display.
Notice
• Ambient Temperature should be kept between 10 and 30 ° C.
• The oscillation system automatically stops when the box door is opened, and automatically starts when it is closed.
• Avoid over-temperature operation, the equipment has an independent temperature limit alarm system (optional).
• Power supply voltage meets requirements (~ 220V 50Hz) before use.
• Pay attention to the stainless steel material of the liner and countertop when cleaning, and use the four-corner arc design for easy operation.
