Overview
SANFA ZHP-Y2102L double-decked thermostatic Shaker is an intelligent device that integrates thermostatic foster and oscillation. It is suitable for bacterial foster, fermentation, hybridization, biochemical reaction and enzyme and cell tissue research that require temperature and Oscillation Frequency. It can perform motion and static foster on microbial cells and various strains.
Features
1. Set thermostatic foster and oscillation in one machine dual-use.
2. Microcomputer Control Temperature and Oscillation Frequency, With Timing Function, LCD Display Display Temperature and Frequency in Real Time, With Over Temperature, Power Outage, Leakage, Sensor Fault Alarm Functions.
3. The Compressor and circulating fan use imported products, environmentally friendly and fluorine-free refrigeration.
4. AC brushless motor, long life, wide speed regulation, constant torque, constant Rotation speed, maintenance-free.
5. Concept aesthetic design, with observation window, liner and Shaker Table surface with antibacterial stainless steel, four corners arc easy to clean.
6. Equipped with a door switch, the oscillation system stops working when the box door is opened, and automatically starts when it is closed.
7. Rotation speed circuit is reasonably controlled to ensure that the Shaker starts slowly and accelerates smoothly to prevent liquid splashing.
8. Independent temperature limit alarm system, automatically cut off the power supply when the temperature exceeds the limit (optional).
9. Upgraded intelligent thermostatic shaking incubator large-screen LCD display, more accurate temperature control, more stable oscillation, can be equipped with RS-485 interface to connect printers and computers (optional).
Principle
The device precisely adjusts the temperature and Oscillation Frequency through a microcomputer Control system, combines environmentally friendly fluorine-free refrigeration technology and AC brushless motor drive, and realizes smooth oscillation in a thermostatic environment to meet the needs of cell fostering and biochemical reactions.
Applications
Bacterial fostering, fermentation, hybridization, biochemical reactions, enzymes and cell tissue studies
Steps
1. Connect the power supply (~ 220V 50Hz).
2. Set the required temperature (RT + 5-65 ° C) and Oscillation Frequency (30-300rpm).
3. Set the Timer Range (1-9999min) as required.
4. Place the sample on the tray and close the box door to automatically start the oscillation.
5. Monitor operating parameters through the LCD display.
Notice
• Equipment Ambient Temperature should be maintained at 10-30 ℃.
• The oscillation system automatically stops when the box door is opened, and automatically starts when it is closed.
• Power supply voltage meets requirements (~ 220V 50Hz) before use.
• Regularly clean liner and Shaker Tables to maintain hygiene.
• Optional features such as independent temperature limit alarm system and RS-485 interface require additional configuration.
