Overview
HUXI LCD Stirrer is a laboratory equipment suitable for mixing medium and high viscosity liquids. It adopts self-locking chuck and self-developed Cube lifting and fixing clip design. The product is capable of high load and long-term continuous work, and has the automatic protection function of overload and abnormal conditions to ensure laboratory safety. It is widely used in chemical synthesis, physical and chemical analysis, petrochemical, cosmetics, health products, food, biotechnology and other fields.
Features
1. LCD screen display, Rotation speed and time can be roughly adjusted, Working time can be fine-tuned under working conditions
2. Speed range 30-2200rpm, constant Rotation speed, high and low speed controllable
3. Adopt brushless DC motor for long-term safe operation
4. Overload and motor protection, if there is an abnormality, automatically cut off the circuit and alarm
5. Configure the Impeller penetration hole, the user does not need to adjust the installation height of the instrument
6. The torque can be automatically adjusted according to the sample viscosity
7. Multiple Impellers and Bracket Available
Principle
The Stirrer drives the Impeller swirl/spin with a brushless DC motor to mix solid-liquid, liquid-liquid or medium to high viscosity samples. With stepless speed regulation, the torque can be automatically adjusted according to the viscosity of the sample to ensure the mixing effect.
Applications
Chemical synthesis, physical and chemical analysis, petrochemical, cosmetics, health products, food, biotechnology
Steps
1. Select the right Impeller and install it
2. Connect the power supply and turn on the device.
3. Rotation speed and time parameters set by LCD screen
4. Working time can be fine-tuned as required
5. Start the mixing procedure for sample mixing
6. Turn off the device after the experiment is completed
Notice
• Before use, please confirm that the Power supply voltage meets the requirements (100-240VAC)
• Ensure that the Ambient Temperature is within the range of 5-40 ° C
• The relative humidity should not exceed 80%
• Pay attention to the clamping diameter range of the Impeller (0.5~ 10mm)
• Avoid overload use, the device will automatically protect
• Use non-slip mats to ensure equipment stability
• Regularly check whether the chuck protective cover is in good condition
