YONGLIDA CSB-3 Zahn Cup Immersion viscosity Cup Stainless steel material 3.76mm aperture

Name: YONGLIDA CSB-3 Zahn Cup Immersion viscosity Cup Stainless steel material 3.76mm aperture
Brand: YongLiDa
SKU: NB003846
Price: 130.0 USD
Availability: InStock

$ 130.00Ex works

Made of stainless steel, aperture 3.76mm, Measurement range 100~ 800cSt, correction factor 0.95~ 1.05, in line with ASTM D4212 standard, suitable for Newton type liquid viscosity test.

Model

CSB-3

Get Quote

Category : Viscosity Cup

Brand : YongLiDa

SKU : NB003846

Service :The delivery and service By NBCLab.Com

Overview

The YONGLIDA CSB-3 Zahn Cup (Immersion) is a portable, immersion viscosity cup, also known as the Zahn Cup, used to test the viscosity of Newtonian or near-Newtonian liquids. This product complies with ASTM D4212-93 Standard Test Method for Immersion Viscosity Cups.

Features

1. Portable immersion design for easy operation 2. Made of stainless steel, including cup body, filter and handle 3. Accurate viscosity measurement range 100~ 800cSt 4. Flow hole diameter 3.76mm, capacity 44ml 5. Correction factor range 0.95~ 1.05 to ensure measurement accuracy

Principle

The CSB Zahn Cup measures viscosity by measuring the time it takes for a liquid to flow out of a standard pore size, based on the ASTM D4212 standard method for viscosity testing of Newtonian or near-Newtonian liquids at 25 ° C +/- 0.2 ° C Ambient Temperature.

Standards

ASTM D4212-93

Steps

1. Immerse the viscosity cup into the liquid to be tested 2. Ensure that the Ambient Temperature is controlled at 25 ℃ +/- 0.2 ℃ 3. measurement of liquid flow time from the cup 4. Calculate viscosity values based on outflow time and correction factor

Notice

• Only suitable for Newtonian or near-Newtonian liquids • Ambient Temperature must be strictly controlled at 25 ℃ +/- 0.2 ℃ • Confirm that the correction factor is within the range of 0.95 to 1.05 before use • Keep the cup body and flow hole clean to avoid blockage • Operate according to ASTM D4212 standard method

Viscosity Range
100~800 cSt
flow hole diameter
3.76mm
capacity
44 ml
Cup body material
stainless steel
Handle material
stainless steel
Applicable standard
ASTM D 4212
Ambient Temperature
25±0.2 ℃
certificate
without
correction factor
0.95~1.05

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
