Overview
FANGZHOU FZ-251 PH Electrode is a professional measurement PH value equipment, using lead-free Glass shell and solid polymer reference electrolysis design, suitable for 0~ 14pH Measurement range and 0~ 80 ℃ temperature environment.
Features
1. Adopt open + ceramic core liquid network design
2. Equipped with long-life reference type
3. Use solid polymer reference electrolysis solution
4. Shell made of Lead-free Glass
5. Glass film is S type
6. Film Impedance Less than 250MΩ
7. Equipped with BNC connector and 1 meter cable
Principle
PH Electrode measures the PH value by sensing the concentration of hydrogen ions in the solution through the Glass film, generating a potential difference. The solid polymer reference electrolysis solution provides a stable reference potential, and the open + ceramic core liquid network part ensures the ion exchange between the electrolysis solution and the sample solution.
Applications
Water quality monitoring, laboratory analysis, industrial process control, environment monitoring, Food processing
Standards
Lead-free environmental standards
Steps
1. Connect the Electrode BNC connector to the pH meter
2. Calibrate with standard buffer
3. Electrode immersion in the solution to be tested
4. Record the PH value after waiting for the reading to stabilize
5. Clean Electrode After Use and Store Properly
Notice
• Avoid collision of Electrode Glass film with hard objects
• Electrode should be cleaned promptly after use
• When not in use for a long time, it should be stored as required
• Avoid use in extreme temperature conditions
• Electrode performance regularly checked and calibrated
