SHIBO SZQ-160 30/60/90/120 Film Applicator Combined quadrilateral stainless steel film Applicator

Name: SHIBO SZQ-160 30/60/90/120 Film Applicator Combined quadrilateral stainless steel film Applicator
Brand: SHIBO
SKU: NB039248
Price: 311.0 USD
Availability: InStock

$ 311.00Ex works

Spreader can be 30/60/90/120μm four thicknesses at the same time, using a combined quadrilateral structure, application width 160mm, stainless steel material to ensure durability and accurate film effect.

Model

SZQ-160 30/60/90/120

Get Quote

Category : Film Applicator

Brand : SHIBO

SKU : NB039248

Service :The delivery and service By NBCLab.Com

Overview

SHIBO SZQ-160 Combination 30/60/90/120 Film Applicator is a combined quadrilateral fabricator with a film thickness of 30/60/90/120μm and a specification of 160x100mm. The product is cylindrical in the middle, quadrilateral at both ends, and has 4 film grooves.

Features

1. Combined quadrilateral design, with cylindrical quadrilateral at both ends in the middle Four wet film thicknesses available: 30μm, 60μm, 90μm, 120μm 3. The application width is 160mm 4. Made of stainless steel 5. Total length 190mm, easy to operate

Principle

The Film Applicator is designed with grooves of different depths to form a wet-film of a predetermined thickness on the surface of the substrate Spreader for subsequent testing and sample preparation.

Applications

Measuring the hiding power of the sample, measuring the color of the sample, and preparing the sample

Steps

1. Select the film groove of the desired thickness 2. Applicator placed on the substrate surface 3. Spreaders form a wet-film of a specified thickness 4. For subsequent testing or sample prepative

Type
Combined quadrilateral fabricator
wet film thickness
30/60/90/120μm
application width
160mm
material
stainless steel
Total length
190mm
