Overview
The LS252DC is an integrated Leeb hardness tester with a compact structure. The instrument detects Hardness according to the Richter Hardness Measurement principle and can perform Hardness measurement on a variety of metal materials. Using excellent dual coil technology, with good Repeatability and Measurement accuracy, the built-in directional Sensor of the probe automatically compensates for measurement errors in different Impact directions.
Features
1. The integrated structure is compact and portable
2. Double coil technology, Repeatability and Measurement accuracy
3. Built-in Direction Sensor automatically compensates for measurement errors in different Impact Directions
4. Built-in a variety of Hardness standards, which can be converted between Richter (HL), Vickers (HV), Brinell (HB), Shaw (HS), and Rockwell (HRA/HRB/HRC)
5. DC Impact device for measurement in bore or cylinder
6. Rechargeable lithium battery power supply, a single charge can be continuously measured more than 5000 times
7. USB (Type-C) charging interface, easy to charge
Principle
The instrument detects Hardness according to the Richter Hardness Measurement principle, and performs Impact testing on metal materials through the Impact device. The built-in Direction Sensor of the probe automatically compensates for the measurement errors of different Impact directions, and the system has a variety of built-in Hardness standards that can be converted to each other.
Applications
Machine tool guides, automotive chassis, heavy workpieces, mold cavities, bearings, Pressure Vessels, installed machinery or assembled parts
Standards
GB/T 13794.1、GB/T 13794.2、GB/T 13794.4、JB/T 9378-2001、JJG 747-1999
Notice
• Operating temperature range: -10~ 50 ℃, humidity 0~ 85% RH (no condensation)
Temperature range: -10~ 60 ℃, humidity 0~ 85% RH (no condensation)
• Measurement accuracy of +/- 12 HL, typical value of +/- 6 HL
• Repeatability to 6HL
• resolution: 1HL
