Overview
SGW-681 automatic video Melting point meter is a High Accuracy analytical instrument of INESA brand. It adopts Android operating system and large screen interface, combined with 720P high definition camera and photoelectric detection technology, which can intuitively observe the whole process of sample melting. The instrument supports automatic and visual Measurement mode. Temperature range covers RT + to 360 ° C. It can process four capillary tubing samples simultaneously, which meets the requirements of Pharmacopoeia and related regulations.
Features
1. Adopt Android operating system and large-screen operation interface
2.30Fps high frame rate high-resolution video, melted video playback is clear and smooth without card
3.720P high definition camera and high Sensitivity photoelectric detection element to ensure intuitive and clear sample observation
4. Can display the initial melting, final melting Linear dispersion, map and video of the sample, high-resolution video can be stored and played back
5. New design integrated heating furnace, using precision platinum resistance, rapid heating, high temperature control accuracy, the application of PID regulation and PWM temperature control technology
6. The light source luminance and detection sensitivity of the photoelectric detection system can be adjusted to support automatic measurement of dark and transparent samples
7. Built-in WIFI and network module to realize networking functions and support seamless data connection and sharing
8. The measurement results can be printed, saved PDF report and exported to computer or U disk
9. Comply with the requirements of the National Pharmacopoeia, GMP, GLP and FDA/21CFR Part11, and have user management authority
10. Using pharmacopoeia capillary tubing, four sample tubes can be measured simultaneously
Principle
The instrument heats the sample through an integrated heating furnace, and uses precision platinum resistance, PID adjustment and PWM temperature control technology to implement precise temperature control. The photoelectric detection system combines 720P high definition camera to monitor the sample melting process in real time, automatically identify the initial and final melting points, and record high-resolution video and Linear dispersion.
Applications
Drug analysis, quality control, scientific research, chemical production
Standards
National Pharmacopoeia, GMP, GLP, FDA/21CFR Part11
Steps
1. Prepare samples and load capillary tubing
2. Insert capillary tubing into instrument sample grade
3. Set measurement parameters and heating rate via touch screen
4. Start automatic measurement process
5. Watch video and melt Linear dispersion
6. Save or export measurement results
Notice
• Power supply voltage matching 100~ 240V range before use
• The size of capillary tubing must meet the specifications of outer diameter φ 1.4mm, inner diameter φ 1.0mm and length 90mm
• Sample height should be controlled within 3mm
• Avoid continuous operation for a long time in a high temperature environment
Measurement accuracy is regularly calibrated
• Ensure storage device compatibility when exporting data
