YONGLIDA QXP0-25 ISO GrindoMeter single-channe GrindoMeter Cr12 molybdenum vanadium steel

Name: YONGLIDA QXP0-25 ISO GrindoMeter single-channe GrindoMeter Cr12 molybdenum vanadium steel
Brand: YongLiDa
SKU: NB004299
Price: 176.0 USD
Availability: InStock

$ 176.00Ex works

Made of Cr12 molybdenum vanadium steel, the range is 0~ 25μm, Graduation 2.5μm, single-channe structure design conforms to ISO standards, suitable for fine particle size detection.

Model

QXP0-25

Get Quote

Category : Fineness Gauge

Brand : YongLiDa

SKU : NB004299

Service :The delivery and service By NBCLab.Com

Overview

YONGLIDA ISO Grindometer is a single-channe Grindometer made of Cr12 molybdenum vanadium steel. It is divided into three models: QXP0-25, QXP0-50, and QXP0-100 according to the detection fineness range, and is equipped with drawdown blades of corresponding sizes. QXP0-25/QXP0-50/QXP0-100 ISO Grindometer can be applied to laboratory testing of GB/1724 standards.

Features

1. Made of Cr12 molybdenum vanadium steel 2. Single-channe Grindometer Design 3. Provide three models of QXP0-25, QXP0-50, and QXP0-100 to choose from 4. Equipped with drawdown blades of corresponding size

Principle

ISO Grindometer scrapes the sample in the scraping groove by drawdown blade, and detects the fineness of the material according to the distribution of the sample on the scraping groove scale.

Applications

Laboratory testing

Standards

GB/T 1724

Steps

1. Prepare the sample to be tested 2. Place the sample at the beginning of the scraping groove 3. Use the matching drawdown blade to scrape the scraping groove uniformly 4. Observe the distribution of the sample on the scale 5. Read the corresponding fineness value

Notice

• Make sure the scraper and drawdown blade are clean and drying before use • Maintain a uniform speed when scraping • Avoid scratches on drawdown blade and groove surface • Clean and maintain in time after use Store in a drying environment

Scraper Type
single-channe
Number of grooves
1
Range
0~25μm
Scale unit
μm
Scraper material
Cr12 molybdenum vanadium
Scraper Size
175*65*13mm
Applicable standard
GB/T 1724
Graduation
2.5μm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
