TRUIT TR 1004/8 French standard Cup NF viscosity Cup 8mm pore size 108ml capacity

Name: TRUIT TR 1004/8 French standard Cup NF viscosity Cup 8mm pore size 108ml capacity
Brand: TRUIT
SKU: NB043167
Price: 128.0 USD
Availability: InStock

$ 128.00Ex works

Using anodic oxidation aluminum alloy material, the outflow time is 30~ 300 seconds, the viscosity range is 700~ 11500cSt, and the material Tack is evaluated by measuring the outflow time of the fixed capacity liquid.

Model

Get Quote

Category : Viscosity Cup

Brand : TRUIT

SKU : NB043167

Service :The delivery and service By NBCLab.Com

Overview

The TR 1004/8 French standard cup is a type of viscosity cup of the TR 1004 series. It is anodic oxidation treated with aluminum alloy material and is suitable for sample testing with a flow time range of 30 to 300 seconds. The product is designed according to the French NFT 30-014 standard for the measurement of inks, Coatings, paints and other Newtonian or near-Newtonian liquids. Tack is evaluated by measuring the time required for the 108ml volume sample in the cup to flow out of the bottom 8mm hole.

Features

1. High-quality aluminum alloy material, anodic oxidation treatment 2. The outflow time range is 30 to 300 seconds 3. The volume is 108ml 4. The diameter of the flow hole is 8mm. 5. The viscosity measurement range is 700~ 11500cSt

Principle

Tack of NF viscosity cups is evaluated by measuring the time it takes for a 108ml volume sample to flow out of the bottom hole. This method is widely used for the measurement of the viscosity of Newtonian or near-Newtonian liquids based on the relationship between liquid flow characteristics and viscosity.

Applications

Inks, Coatings, paints

Standards

NFT 30-014

Steps

1. Prepare the liquid sample to be tested 2. Pour sample into viscosity cup to 108ml capacity 3. Record the time required for the sample to completely flow out of the bottom 8mm hole 4. Evaluate Material Tack Based on Outflow Time

Notice

• Only suitable for sample testing with outflow time in the range of 30 to 300 seconds • Suitable for viscosity measurement of Newtonian or near-Newtonian liquids • Make sure the viscosity cup is clean and drying before use Maintain stable environmental conditions during measurement

flow hole diameter
Φ8.0mm
outflow time
30 to 300 seconds
Viscosity Range
700~11500cst
capacity
108ml
Cup body material
High quality aluminum alloy (anodic oxidation)
