Overview
Micrometer Film Applicator TR 3101/250 is an experimental tool for Spreader liquid or slurry on different surfaces, with the characteristics of adjustable film Film thickness. It consists of a high-quality alloy steel scraper and an adjustable bracket. The scraper adopts a magnetic suction design for easy replacement and cleaning. The bracket can freely adjust the film Film thickness from 0 to 3000μm. It is suitable for Moulding proofing in Coating, inks, Adhesive, New material and other industries.
Features
1. The scraper is made of high-quality alloy steel, High Accuracy, High Hardness, Wear Resistance and Corrosion Resistance
2. The bracket is anode-treated aluminum alloy, non-decolorizing, acid and alkali resistance, corrosion resistance
3. Magnetic scraper for easy cleaning
4. Spreader width 250mm, wet film thickness 0~ 4500μm
5. The reading method is scale value, resolution 10
6. Scraper error +/- 2μm, differential head accuracy +/- 2μm
Principle
The Micrometer Film Applicator can adjust the lower scraper in the upper and lower directions to control the gap by adjusting the two differentiators above the Applicator, so as to control the final Coating thickness. The bracket has the function of adjusting the film film thickness, and the spacing can be freely adjusted from 0 to 3000 μm to meet the diverse needs of Moulding of different materials.
Applications
Coatings, inks, Adhesives, New materials and other industries Moulding proofing, laboratory Coater supporting use
Steps
1. Adjust the two differentiators above the Applicator to control the scraper gap
2. Set the required film Film thickness
3. Spreader operation
4. Clean the magnetic scraper in time after use
