Overview
The manual unwinding type comma Coater is a special equipment used to evenly Spreader liquid materials on the surface of the material, such as Adhesive, inks, Coating, etc. The device has an effective Spreader width of more than 280mm, the Spreader speed is manually dragged by the operator, and the Spreader Film thickness range is 2um-1.1mm. It is suitable for production Spreader, sample preparation and R & D testing in printing, Encasement, electronics, Spinning & weaving and other industries.
Features
1. The effective Spreader width is more than 280mm, which can adapt to the material requirements of different sizes and ensure that the Spreader is uniform
2. Spreader speed Manual drag control, you can adjust the speed as needed to achieve accurate Spreader
3. Spreader Film thickness range is wide, from 2um to 1.1mm, to meet the requirements of nano film to millimeter thick film Spreader
4. The lower plane of the Spreader head is made of special steel grinding, and the comma stick is made of special steel + hard chrome plating + grinding to ensure accuracy and durability
5. Dry adhesive accuracy up to +/- 0.002mm, providing reliable quality control
Principle
The Coater evenly Spreader liquid material on the surface of the material by means of a comma Coater blade (comma stick). The operator manually drags the material to control the speed of the Spreader, and the comma stick places liquids such as Adhesive, inks or Coating on the material at a set Film thickness Spreader, achieving a Spreader Film thickness range from 2um to 1.1mm.
Applications
Printing, Encasement, Electronics, Spinning & weaving
Steps
1. Spreader Materials and Liquid Coatings
2. Adjust the Coater settings to ensure that the Spreader width and Film thickness meet the requirements
3. Manually drag the material through the Spreader area to control the Spreader speed
4. Spreader process to ensure uniformity and conformity
5. After finishing the Spreader, check the Spreader mass and perform follow-up processing
Notice
• Make sure the equipment is clean before operation to avoid impurities affecting the Spreader mass
• Keep the speed even when manually dragging to prevent uneven Spreader Film thickness
• Adjust the operating parameters according to the glue viscosity (100~ 10000CPS)
• Regularly check the abrasion of the Spreader head and comma stick, and maintain it in time
• Spreader process pay attention to safety, avoid material sliding or liquid splashing
