Overview
The TD1002C Tianma Precision Balance is a trapezoidal dial precision electronic Analytical Balance with a maximum range of 100g and an accuracy of 0.01g, using a digital tube display. The Balance is equipped with a 100g test weight and is externally corrected.
Features
1. International unit conversion function.
2. AC and DC dual-use function.
3. Digital tube display.
4, equipped with a test weight.
5. Counting function (point function), which can be easily used for counting Balance.
6, with peeling, weighing Automatic calibration, automatic clearing, zero point automatic tracking and fault display functions.
Principle
The TD1002C Precision Balance is calibrated with an external Calibration method using the equipped 100g test weight to ensure weighing accuracy. During the weighing process, Balance automatically performs functions such as peeling, Automatic calibration, automatic clearing and automatic zero tracking to provide stable and accurate measurement results.
Applications
Precision weighing, laboratory analysis, counting applications
Steps
1. Place the Balance on the stable table and connect the Power Adapter.
2. Turn on the power switch and wait for the Balance initialization to complete.
3. Use the equipped 100g test weight for external calibrating.
4. Place the items to be tested on the trapezoidal pan for weighing.
5. Select the counting function or Other functions as needed.
6. Read the measurement results on the digital tube display screen.
Notice
• Ensure that the Working Ambient Temperature is within the range of 5~ 40 ℃ and Humidity is within the range of 50% RH~ 60% RH.
• It must be externally calibrated before use to ensure accuracy.
• Avoid operating on vibrating or unstable surfaces.
• Regularly clean the pan to prevent dust from affecting the measurement.
• If there is a fault display, please check the operation or contact technical support.
