Overview
HUITAI DHG-9075A blast drying oven is a equipment used by industrial and mining enterprises, laboratories, R & D institutions, etc. It is mainly used for drying, baking wax melting, sterilizing and other purposes. This model is equipped with a test hole of 50mm, with precise temperature control and various safety functions.
Features
1. Large-screen LCD display, multiple sets of data are displayed on one screen, menu-type operation interface, simple to understand and easy to operate (standard).
2. Control mode of fan speed is adopted to improve the temperature uniformity of the studio.
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box without manual adjustment.
4. Adopt microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, accurate and reliable temperature control.
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient.
6. Cold rolled steel plate, electrostatic spray on the surface.
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional).
8. With RS485 interface, the recorder and computer can be connected, and the change of temperature parameters can be recorded (optional).
Principle
Control mode of the blower speed and speed, combined with the self-developed air duct circulation system, the blower drying oven realizes the uniform distribution of the temperature in the studio and automatically discharges water vapor. The microcomputer temperature controller provides accurate temperature control and over-temperature protection to ensure the stable operation of the equipment.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
Connect the power supply and ensure that the voltage is AC 220V 50Hz.
2. Set parameters such as temperature and timing through the large-screen LCD display menu.
3. Start the equipment, and the fan automatically runs to heat evenly.
4. The equipment automatically controls the temperature and discharges water vapor.
5. After the timing expires, the device automatically stops or shuts down manually.
Notice
• Power supply voltage meets AC 220V 50Hz requirements.
• Check whether the independent temperature limit alarm system (if optional) is normal before use.
• Regularly clean liners and shelves to maintain equipment performance.
• Avoid over-temperature use to prevent accidents.
• Optional functions such as RS485 interface need to be properly connected to external devices.
