Overview
HUITAI BPG-9140A precision blast drying oven is a equipment suitable for industrial and mining enterprises, laboratories, R & D institutions and other scenes, mainly used for drying, baking, wax melting and sterilizing. It adopts advanced control system and structural design to ensure easy operation and reliable performance.
Features
1. Large-screen LCD display, one-screen display of multiple sets of data, menu-style operation interface, simple to understand and easy to operate.
2. Control mode of fan speed is adopted to improve the temperature uniformity of the studio.
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box without manual adjustment.
4. Adopt microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, accurate and reliable temperature control.
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient.
6. Cold rolled steel plate, electrostatic spray on the surface.
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional).
8. With RS485 interface, the recorder and computer can be connected, and the change of temperature parameters can be recorded (optional).
Principle
The drying oven precisely controls the temperature through a microcomputer temperature controller, combines the fan speed adjustment and air duct circulation system, and realizes uniform heating and automatic water vapor discharge in the working room. The independent temperature limit alarm system automatically interrupts the operation when it exceeds the temperature to ensure safety.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
Connect the power supply and ensure that the voltage is AC 220V 50Hz.
2. Turn on the power switch of the device.
3. Set temperature, timing and other parameters through the large-screen LCD display interface.
4. Start the equipment, the fan starts to work, drying, baking and other operations.
5. Monitor the running status and use optional functions such as RS485 interface to record data if necessary.
6. After the operation is completed, turn off the power and clean the equipment.
Notice
- Power supply voltage meets AC 220V 50Hz requirements to avoid overload.
- Check whether the equipment is in good condition before operation, and stop using it in time if there is any abnormality.
- Do not exceed the Temperature range RT + 10~ 300 ℃ to prevent equipment damage.
- Regularly clean liners and shelves to maintain equipment hygiene.
Optional features such as an independent temperature limit alarm system need to be installed and used correctly.
- Do not block the ventilating port when the equipment is running to ensure the normal circulation of the air duct.
When not in use for a long time, disconnect the power supply and store it properly.
