Overview
HUITAI BPG-9420A + test hole 50mm precision blast drying oven is suitable for drying, baking wax melting and sterilizing in industrial and mining enterprises, laboratories, R & D institutions, etc. The equipment has a 420L studio volume, uses mirrored stainless steel liner and Cold rolled steel plate shell, equipped with microcomputer temperature controller and air duct circulation system.
Features
1. Large-screen LCD display, one-screen display of multiple sets of data, menu-type operation interface, simple to understand and easy to operate
2. Control mode of fan speed is adopted to improve the temperature uniformity of the studio
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box
4. Microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, accurate and reliable temperature control
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient
6. Cold rolled steel plate, electrostatic spray on the surface
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional)
8. With RS485 interface, it can be connected to a recorder and a computer, capable of recording changes in temperature parameters (optional).
Principle
The drying oven achieves uniform temperature distribution in the studio through fan speed control, and adopts the self-developed air duct circulation system to automatically discharge water vapor inside the box. The microcomputer temperature controller precisely controls the temperature, and is equipped with over-temperature deviation protection and timing functions to ensure the stable and reliable operation of the equipment.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
1. Connect the AC220V 50Hz power supply
2. Set the required temperature and time parameters through the menu operation interface
3. Start the device and start working
4. The equipment automatically controls the temperature and completes the setting program
Notice
• Power supply voltage AC220V 50Hz before use
• The setting temperature must not exceed the upper limit of 300 ° C
• Regularly clean liners and shelves
• Optional independent temperature limit alarm system provides additional security
• Optional RS485 interface can realize temperature parameter recording function
