Overview
HUITAI BPG-9620A + test hole 50mm precision blast drying oven is suitable for drying, baking wax melting and sterilizing in industrial and mining enterprises, laboratories, R & D institutions, etc. The equipment adopts large-screen LCD display and microcomputer temperature controller, with precise temperature control and timing functions. The liner is made of mirror stainless steel, and the shell is made of Cold rolled steel plate.
Features
1. Large-screen LCD display, multiple sets of data are displayed on one screen, and the menu-type operation interface is simple to understand and easy to operate.
2. Control mode of fan speed is adopted to improve the temperature uniformity of the studio.
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box.
4, with over-temperature deviation protection, digital display microcomputer temperature controller, with timing function, accurate and reliable temperature control.
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient.
6. Cold rolled steel plate is used for the casing of the box, and the surface is electrostatic sprayed.
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents. (optional)
8. With RS485 interface, it can be connected to a recorder and a computer, capable of recording changes in temperature parameters. (optional)
Principle
The drying oven achieves uniform temperature distribution in the studio through fan speed control, and automatically discharges water vapor with self-developed air duct circulation system. The microcomputer temperature controller precisely controls the temperature and has the function of over-temperature deviation protection to ensure the safe and stable operation of the equipment.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
1. Connect the power supply and set the required temperature and time parameters.
2. Start the equipment, the fan starts to work, and the temperature gradually rises to the set value.
3. The equipment automatically maintains the thermostatic state and automatically stops heating after the timing is over.
Notice
• Power supply voltage meets equipment requirements (AC380V 50HZ)
• Do not exceed the maximum Temperature range (RT + 10~ 300 ℃)
• Regularly clean the liner and keep the equipment hygienic
• Optional functions require additional corresponding accessories
• Do not open the box door at will when the equipment is running
