Overview
HUITAI BPG-9920A + test hole 50mm precision blast drying oven is a desktop equipment suitable for drying, baking wax melting and sterilizing in industrial and mining enterprises, laboratories, R & D institutions, etc. It has a large screen LCD display, precise temperature control and multiple safety protection functions to ensure the Reliability and safety of the experiment.
Features
1. Large-screen LCD display, multiple sets of data are displayed on one screen, menu-type operation interface, simple to understand and easy to operate (standard).
2. Control mode of fan speed is adopted to improve the temperature uniformity of the studio.
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box without manual adjustment.
4. Adopt microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, accurate and reliable temperature control.
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient.
6. Cold rolled steel plate, electrostatic spray on the surface.
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional).
8. With RS485 interface, the recorder and computer can be connected, and the change of temperature parameters can be recorded (optional).
Principle
The drying oven precisely adjusts the heating system through the microcomputer temperature controller, combines the fan speed control and the air duct circulation system, realizes the uniform temperature distribution in the working room and automatically discharges water vapor, ensuring the stability of the drying, baking and other processes.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
1. Connect the power supply and ensure that the voltage is AC380V 50Hz.
2. Set temperature, time and other parameters through the large-screen LCD display interface.
3. Start the equipment, fan, and heating system to start working.
4. Monitor temperature changes, and the device automatically controls and records data (e.g. optional RS485 interface).
5. After completing the set time, the device will automatically stop or manually shut down.
Notice
• Power supply voltage meets AC380V 50HZ requirements to avoid overload.
• Check whether the independent temperature limit alarm system (if optional) is normal before operation to prevent overtemperature accidents.
• When cleaning the liner, use the freely removable shelf bracket and semi-circular four-corner design to pay attention to safety.
• Regularly check the air duct circulation system to ensure that the automatic discharge of water vapor function is effective.
• When using optional accessories such as RS485 interface, connect the recorder or computer correctly according to the instructions.
