Overview
QTG 75/100μm Double Sided Applicator is a laboratory manual film applicator with film Film thickness of 75μm and 100μm, Spreader width 80mm, total length 100mm, film accuracy +/- 2μm. Made of high carbon chromium wear-resistant and anti-corrosion stainless steel, it is tested by imported three-coordinate before leaving the factory for dimensional accuracy to ensure film accuracy. It is suitable for Moulding of glues, Coating paints, inks, polymer materials, etc., and can be equipped with Film Applicator to automatically scrape film.
Features
1. Made of 9Cr18Mo High Hardness Stainless Steel, with Good Abrasion Resistance and corrosion resistance, Hardness value of 50~ 55HRC
2, film accuracy of +/- 2μm
3. Smooth surface, diverse styles, wide range of applications, support for customized specifications
4. Adopt imported three-coordinate detection accuracy, with factory inspection report, can stand Measurement
Principle
Film Applicator manually scrapes the substrate to create a uniform wet-film, and the double-sided design offers two different film thickness options to ensure film accuracy and conformity.
Applications
Glue, Coating paints, inks, Polymer materials
