Overview
Impact Tester is a kind of equipment used to test plastic, Pottery and porcelain, acrylic, fiberglass and other materials and Coating firmness. This equipment complies with JIS-K6745, A5430 test standards, by the specified weight of steel balls from the adjustable height to freely drop the sample, evaluate the degree of damage to judge the product mass, well received by manufacturers.
Features
1. The drop height of the falling ball is adjustable from 0-2000mm
2. Adopt DC electromagnetic control to drop the ball
3. Provide a variety of steel ball weight options: 55g, 64g, 110g, 255g, 535g
4. Low power requirements: 220V, 50HZ, 2A
5. Compact structure: Dimension about 50 * 50 * 220cm, weight about 15kg
Principle
Through DC electromagnetic control, the steel ball of the specified weight is adjusted to the set height and released freely, so that it falls on the sample material. Impact the material firmness and product mass by observing the degree of damage to the sample.
Applications
Plastics, Pottery and porcelain, acrylic, fiberglass and other materials and Coatings
Standards
JIS-K6745、A5430
