PUSHEN BY-III (K) Pendulum Hardness Tester film resilience viscoelasticity Tester

Name: PUSHEN BY-III (K) Pendulum Hardness Tester film resilience viscoelasticity Tester
Brand: Pushen
SKU: NB045154
Price: 1634.0 USD
Availability: InStock

$ 1634.00Ex works

Using 200g swing Rod mass and 5mm steel ball diaMeter, automatic counting function can accurately measure coating soft Hardness, swing cycle 1.4s to ensure Data Reliability.

Model

Get Quote

Category : Persoz / König Pendulum Hardness Tester

Brand : Pushen

SKU : NB045154

Service :The delivery and service By NBCLab.Com

Overview

PUSHEN BY-III (K) Pendulum hardness tester is an instrument for measuring film resilience and viscoelasticity. The principle is to support two stainless steel balls on the Pendulum hardness tester on the drying coating, and determine the film resilience by measuring the swing time of the swing rod. The softer the coating surface, the faster the swing decay.

Features

1. Adopt Konig pendulum type 2. The swing rod mass is 200g 3. The diameter of the steel ball is 5mm. 4. The initial swing angle is 6 ° 5. The end point swing angle is 3 ° 6. The swing period is 1.4s 7. Glass swing time is 250 +/- 10s 8. Equipped with automatic counting function 9. Dimensions 400 × 400 × 780mm 10. The shipment weight is 40kg

Principle

Two stainless steel balls on the Pendulum hardness tester were supported on the drying coating, and the film resilience was determined by measuring the swing time of the swing rod. The softer the coating surface, the faster the swing of the swing rod attenuates.

Specifications

Swing bar type: Konig pendulum, swing bar mass: 200g, ball diameter: 5mm, initial swing angle: 6 °, end swing angle: 3 °, swing period: 1.4s, swing time on Glass: 250 +/- 10s, counting function: automatic, Dimension: 400 × 400 × 780mm, instrument weight: 500 × 460 × 950mm, shipment weight: 40kg

pendulum needle
Konig pendulum
Swing rod weight
200g
Ball diameter
5mm
Initial swing angle
6°
terminal swing angle
3°
swing period
1.4s
Glass swing time
250±10s
counting function
automatic
Dimension
400*400*780mm
instrument weight
500*460*950mm
Shipment weight
40kg

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
