PUSHEN BY-III (KP) Pendulum Hardness Tester K + P pendulum, automatic counting double pendulum

Name: PUSHEN BY-III (KP) Pendulum Hardness Tester K + P pendulum, automatic counting double pendulum
Brand: Pushen
SKU: NB045156
Price: 1698.0 USD
Availability: InStock

$ 1698.00Ex works

Measurement accuracy is ensured by the automatic counting function and the coating attenuation characteristics are determined by the stainless steel ball support.

Model

Get Quote

Category : Persoz / König Pendulum Hardness Tester

Brand : Pushen

SKU : NB045156

Service :The delivery and service By NBCLab.Com

Overview

The PUSHEN BY-III (KP) Pendulum hardness tester is an instrument for measuring film resilience and viscoelasticity. The principle is to support two stainless steel balls of the Pendulum hardness tester on the drying coating. The film resilience is determined by measuring the swing time of the swing rod. The softer the coating surface, the faster the swing of the swing rod decays.

Features

1. Double pendulum design with Konig pendulum and Persoz pendulum 2. The swing rod mass is 200g and 500g respectively 3. Steel ball diameters are 5mm and 8mm respectively 4. The initial swing angles are 6 ° and 12 °, respectively. 5. End point swing angles are 3 ° and 4 °, respectively 6. The swing period is 1.4s and 1s respectively 7. Glass swing time is 250 +/- 10s and 430 +/- 15s respectively 8. Equipped with automatic counting function 9. Dimensions 400 × 400 × 780mm 10. The shipment weight is 40kg

Principle

Pendulum hardness tester two stainless steel balls supported on the coating after drying, swing rod at a certain period of swing. Determine the film resilience by measuring the swing time of the swing rod. If the coating surface is softer, the swing of the swing rod decay faster.

Steps

1. Place the film under the swing bar 2. Start the swing lever to make it swing 3. The instrument automatically counts and measures the swing time of the swing rod 4. Determine film resilience based on swing time

pendulum needle
K + P pendulum
Swing rod weight
200g/500g
Ball diameter
5mm/8mm
Initial swing angle
6°/12°
terminal swing angle
3°/4°
swing period
1.4s/1s
Glass swing time
250±10s/430±15s
counting function
automatic
Dimension
400*400*780mm
instrument weight
500*460*950mm
Shipment weight
40kg

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
