QIWEI JFS-1100E High Speed Variable Frequency Disperser Test Multi-purpose Disperser Variable Frequency Motor 8000rpm

Name: QIWEI JFS-1100E High Speed Variable Frequency Disperser Test Multi-purpose Disperser Variable Frequency Motor 8000rpm
Brand: QiWei
SKU: NB045867
Price: 702.0 USD
Availability: InStock

$ 702.00Ex works

The frequency conversion motor is used to achieve stepless speed regulation of 60~ 8000rpm, and the digital PID control accuracy is high. It is equipped with dispersed impellers and sand grinding blades to adapt to different experimental needs, and the relationship between material viscosity and reaction rate can be directly calculated.

Model

Get Quote

Category : Disperser

Brand : QiWei

SKU : NB045867

Service :The delivery and service By NBCLab.Com

Overview

JFS-1100E high-speed variable frequency Disperser is a new environmentally friendly laboratory product designed and developed by QIWEI brand using new technologies at home and abroad. The product integrates stirring, grinding and dispersing functions. It adopts variable frequency motor, which has the advantages of small size, low noise, no commutation interference, no carbon brush mechanical abrasion, etc. The number directly displays the rotating shaft Rotation speed, and is equipped with a dispersing impeller and a grinding blade disc, which can adapt to different laboratory test needs and provide correct data for large-scale production.

Features

1. Adopt square tube chain lifting system, easy to lift. 2. Adopt a new type of variable frequency motor, realize stepless speed regulation through smart variable frequency controller, apply digital PID technology, high control accuracy, 4 digital tube directly displays the spindle Rotation speed. 3. Disperse impeller and sand grinding blades are directly connected to the shaft with screws. 4. The cylinder is fixed by the left and right grippers, and the cylinder body adopts a jacket structure, which can be processed from stainless steel by chilling down water.

Principle

This equipment is driven by frequency conversion motor, using smart frequency conversion controller to implement stepless speed regulation of the motor, applying digital PID technology implementation High Accuracy control, digital direct display shaft Rotation speed. Disperse impeller and sand grinding disc are directly connected to the shaft, and adjust the position through the lifting system to adapt to different experimental needs.

Applications

laboratory

Motor Power
1100W
Speed Range
Frequency conversion speed regulation 60~ 8000rpm
Stirring dispersion impeller diameter
Φ50mm；Φ60mm；Φ80mm
Lift Travel
200mm
Power supply Voltage
220V 50HZ
Dimension
400*450*800mm
Sanding disc diameter
Φ60mm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
