Overview
The CBGL-1000B electric air blowing dryer adopts a novel vertical design, and the shell is a high-quality steel plate treated by electrostatic spray, which is beautiful and durable. The studio is made of stainless steel and has undergone anti-corrosion process, with four corners and arc transition, Shelf spacing is adjustable, and the side plate of the air duct and the bottom heating cover are quick-release structure for easy cleaning. The box door adopts a new structure with good heat insulation effect, equipped with double-decked tempered Glass large viewing window, lock-type elastic adjustment door lock and high temperature resistant silicone sealing strip to ensure good sealing and prevent heat loss.
Features
1. High Accuracy, Large Capacity, Efficient, Safe, Wide Range
2. PID temperature controller and microcomputer temperature control, accurate temperature control
3. Dedicated function keys to achieve temperature setting
4. Auxiliary menu supports over-rise alarm, deviation correction, menu lock
5. Operation functions include timing operation, temperature deviation correction, menu lock, power failure memory
6. Optional 485 interface, printer, programmable temperature controller
7. Independent temperature limiting function
8. Safety devices include over-temperature alarm and power-off protection
Principle
The electric air blowing dryer achieves thermostatic circulation through the fan, the heating device uses stainless steel heating pipe to generate heat, and the PID temperature controller and microcomputer precisely control the temperature to ensure uniform and stable temperature in the box. The heat insulation material and sealing structure of the box effectively prevent heat loss and maintain the set temperature.
Applications
Drying, heating, experiment, industrial treatment
Steps
1. Connect 380V 50HZ power supply
2. Use the touch button to set the temperature
3. Set the timing function as needed (0-9999 minutes)
4. Start the equipment and the fan cycle starts to work
5. Monitor temperature through LCD display
6. Turn off the power after use
Notice
• Make sure the power supply is 380V 50HZ
• Temperature range is RT + 10-300 ℃, avoid using beyond the range
• Regularly clean the side plate and bottom heating cover of the air duct to keep the quick dismantling structure open
• Pay attention to over-temperature alarms and power-off safety devices, and deal with abnormalities in a timely manner
• Shelf bearing no more than 25KG to avoid overload
• Pay attention to the sealing of the box door during operation to prevent heat loss
