Overview
MS-CZ200 Weighing Large Capacity Magnetic Stirrer is a HUXI brand product. It uses the principle of magnetic field coupling to transfer the stirring power to the movable stirrer at the bottom of the ingredients barrel to achieve liquid mixing. The equipment adopts a no-mechanical connection design to avoid the risk of pollution, meets the hygiene requirements of the pharmaceutical industry, and integrates the function of an electronic scale. It can mix liquids in proportion and is easy to operate. It is suitable for non-viscous pharmaceutical liquids, beverage ingredients and filling stirring and mixing. It is widely used in biological products cell foster, laboratory and other pharmaceutical fields.
Features
1. Integrate weighing and magnetic stirring
2. The chassis is all formed by bending 304 stainless steel
3. Brushless DC motor with new computer closed-loop control, large torque, accurate setting
4. Using Excellent Sensor, Repeatability of Accurate Measurement, Wide Measurement range, Multiple Range to choose from
5. Use a variety of specifications mixing bucket, so small size, light weight, no leakage, low abrasion, no dead angle, easy to clean, sterilize
Principle
MS-CZ200 Magnetic Stirrer uses the principle of magnetic field coupling to transfer the stirring power to a movable stirrer at the bottom of the batching barrel, which mixes the different liquids in the barrel in swirl/spin. Since there is no mechanical connection, the risk of contamination is avoided.
Applications
Cell fostering of biological products, laboratory and other pharmaceutical industries, pharmaceutical liquids, beverage ingredients and filling mixing
Steps
1. Place the stirrer at the bottom of the batching bucket
2. Place the dispensing drum on the Stirrer countertop
3. Connect power supply AC220V +/- 10%
4. Set stirring speed 20-1000r/min
5. Use the electronic scale function for weighing and proportional mixing
Step 6 Start the mixing process
Notice
• Only suitable for mixing non-viscous liquids
• Power supply voltage within AC220V +/- 10%
• Check whether the stirrer is in good condition before use
• Regularly clean and sterilize equipment
• Avoid overloading, weighing up to 500kg
