Overview
HUXI HMS-206 heating Magnetic Stirrer is specially designed for Applications with higher requirements for Processing capacity, temperature and Power. After the upgrade, the performance is better, the function is stronger, and the application range is wider. It is suitable for stirring or heating at the same time. The viscosity is not very large. Liquid or solid-liquid mixture.
Features
1. Aluminum die casting ceramic coating work plate abrasion resistance, corrosion resistance, high temperature oxidation resistance
2. Wide Temperature range, the highest temperature can reach 350 ℃, heating function is controlled separately, and the button is highlighted after heating is turned on
3. Internal and external temperature sensor PT1000, can precisely control the temperature accuracy to +/- 0.2 ℃
4. Adopt LCD liquid crystal display with backlight design, which is convenient for setting and monitoring data during operation
5. LCD display real-time display of temperature, Rotation speed and running time
6. With time setting function, can be set to 0~ 99h59min
7. DC brushless motor, low noise, low maintenance, smooth operation, long service life
8. Dual heating control circuit, when a heating circuit fails, it can continue to maintain temperature stability
9. The knob has the function of running lock and anti-misoperation to prevent accidental change of running state
10. Pressed aluminum sealing insulation shell effectively prevents liquid and gas from entering the inside of the instrument and protects circuit components from corrosion
Principle
The heating type Magnetic Stirrer realizes the stirring function by magnetically driving the stirrer to swirl/spin in the container, and at the same time heats the working plate through the heating tube. The temperature sensor PT1000 is connected inside and outside to accurately monitor and control the temperature, so as to realize the synchronization or separate operation of stirring and heating.
Applications
Laboratory stirring, heating stirring, liquid mixing, solid-liquid mixture treatment, parallel reaction
Standards
Power supply voltage 220V, Rated Frequency 50~ 60Hz
Steps
Step 1 Place containers and stirrers
Step 2 Connect the power supply
3. Set the required temperature
4. Set stirring speed
5. Set the running time (if necessary)
6. Turn on the heating function
Step 7 Start mixing
8. Monitor operating status
Notice
• Only for liquids or solid-liquid mixtures where viscosity is not very large
• The applicable range of the stirrer is 20-80mm
• Max. Capacity of stirring 20L
• Permissible Ambient Temperature 5~ 40 ℃
• Allowable relative humidity of 80%
• Make sure the container matches the size of the heating area before use
• Note that the overtemperature protection temperature is ≤ 420 ° C
• Pay attention to the knob locking function when operating to prevent misoperation
