Overview
The SUOGUANG MPZ-3B Microcomputer Melting point meter is a High Accuracy melting point measuring device using capillary method, which meets the requirements of national verification regulations. The instrument has a three-channel simultaneous measurement design, which significantly improves the detection efficiency, and is equipped with intelligent LED luminance adjustment and 7-inch color Touchscreen, providing a superior user experience.
Features
1. Simultaneous measurement of three channels, three times the efficiency, accurate identification of melting points
2. Three Operating Modes: Standard Mode, Long Melting Moment Mode and Learning Mode to meet various sample measurement requirements
3. LED luminance intelligent adjustment, optimize observation conditions
4.7-Inch Color Touchscreen and Exquisite UI Design Enhance Operation Convenience
5. Two-level user management (administrator and ordinary user), support password login, modification and permission editing
6. Automatically generate measurement reports, store up to 10,000 sets, can be exported to the computer
7. Audit Trail Function, Supports Data Traceability, Especially Suitable for Pharmaceutical Raw Materials Factory
Principle
Based on the principle of capillary method, the instrument precisely controls the heating rate (0.1 ℃/min~ 30 ℃/min stepless speed regulation), monitors the state change of the sample during the heating process in real time, and automatically recognizes the melting point temperature. Using a three-channel design, multiple sample measurements can be performed simultaneously to ensure data accuracy and Repeatability.
Applications
Pharmaceutical factories, food raw materials, fragrances and flavors, fine chemicals, university laboratories
Standards
Capillary melting point tester verification specification
Steps
1. Turn on the power of the instrument and log in to the user account through Touchscreen
2. Select Operating Mode (Standard Mode, Long Melting Moment Mode or Learning Mode)
3. Set the starting temperature, heating rate and other parameters
4. Place the sample capillary tubing to the three channel measurement position
5. Start the measurement process, the instrument automatically monitors and records the melting point data
6. After the measurement is completed, view or export the measurement report
Notice
• Ensure that the starting temperature setting is accurate and the error does not exceed 0.05 ° C
• Select the appropriate heating rate according to the sample characteristics to reduce the error
• Regularly calibrate instruments to ensure Measurement accuracy meets standards
• Pay attention to data backup when storing measurement reports to avoid loss
• Use administrator privileges for sensitive operations to ensure data security
