Overview
The SUOGUANG MPZ-3B + microcomputer Melting point meter is a high-performance melting point measuring device that uses capillary method for accurate melting point measurement. The instrument has three-channel simultaneous measurement function, which significantly improves efficiency, and supports multiple Operating Modes to adapt to different sample requirements. It is widely used in the fields of medicine, food raw materials, fragrances, fine chemicals, and university laboratories.
Features
1. Three-channel simultaneous measurement, three times the efficiency, accurate identification of melting points.
2. Three Operating Modes: Standard Mode, Long Melting Moment Mode, and Learning Mode to meet various sample measurement requirements.
3. LED luminance intelligent adjustment.
4.7-Inch Color Touchscreen and beautiful UI design optimize user experience.
5. Two-level user management: administrators and ordinary users, support password login, modification, and permission editing.
6. Automatically generate measurement reports, with a storage capacity of up to 10,000 sets, which can be exported to the computer.
7. With audit trail function, suitable for data Traceability requirements.
Principle
The instrument is based on the principle of capillary method for melting point measurement. By precisely controlling the heating rate and Temperature range, the melting process of the sample is automatically monitored, and the melting point data is accurately collected and analyzed.
Applications
Pharmaceutical factories, food raw materials, fragrances and flavors, fine chemicals, university laboratories
Standards
Capillary melting point tester verification specification
Steps
1. Turn on the instrument power and log in to the user account through Touchscreen.
2. Select Operating Mode (Standard, Long Melt Moment or Learning Mode).
3. Set the starting temperature, heating rate and other parameters.
4. Place the sample capillary tubing into the measurement channel.
5. Start the measurement process, the instrument automatically monitors and records the melting point data.
6. After the measurement is completed, view and export the measurement report.
Notice
• Ensure that the instrument meets relevant standards before use.
• Temperature range and heating rate limit when setting parameters.
• Sample placement should be accurate to avoid affecting Measurement accuracy.
• Maintain the instrument regularly to ensure that the LED and Touchscreen function properly.
When storing and exporting data, pay attention to user rights management.
