TRUIT TR 5120/KP Pendulum Hardness Tester according to GB/T 1730 ISO 1522 ASTM D4366

Name: TRUIT TR 5120/KP Pendulum Hardness Tester according to GB/T 1730 ISO 1522 ASTM D4366
Brand: TRUIT
SKU: NB047356
Price: 1475.0 USD
Availability: InStock

$ 1475.00Ex works

The electromagnet cissing pendulum is used, which can adapt to the thickness test plate of 0.1mm to 5.5mm, and is equipped with two laser Probe to record data. The swing period is 1.4 seconds and 1 second respectively, and the organic Glass door cover reduces the influence of airflow.

Model

TR 5120/KP

Get Quote

Category : Persoz / König Pendulum Hardness Tester

Brand : TRUIT

SKU : NB047356

Service :The delivery and service By NBCLab.Com

Overview

TRUIT TR 5120/KP Pendulum hardness tester is an instrument designed in accordance with GB/T 1730, ISO 1522 and ASTM D4366 standards. It adopts the principle of KÖnig pendulum and Persoz pendulum and double pendulum. Hardness is measured by the oscillation attenuation of the pendulum rod on the film surface. It is suitable for different thickness test plates.

Features

1. Touchscreen control 2. Use electromagnet cissing pendulum 3. Can be suitable for test plates of different thicknesses from 0.1mm to 5.5mm 4. Data Recording with Two Laser Probes 5. Organic Glass door cover, reducing air circulation and convenient viewing 6. Freely switch between different test methods

Principle

The Pendulum hardness tester is based on the interaction between the pendulum and the paint film, depending on the film resilience and viscoelasticity properties. The softer the pendulum touches the film surface, the faster its pendulum radiation attenuates. Hardness is assessed by the measurement of damping time. The Koenig pendulum and the Persaz pendulum share the same principle but differ in size, oscillation period and oscillation.

Applications

Paints and varnishes

Standards

GB/T 1730、ISO 1522、ASTM D4366

Notice

On surfaces with low friction factors, the Persoz pendulum may slip, invalidating the results • Tests should be carried out under controlled temperature and Humidity conditions without the influence of airflow • Film thickness and substrate material may affect damping time • Only one type of swing bar is allowed in the specified damping time measurement

Swing bar Type
Koenig + Persaz pendulum
Swing rod weight
200g±0.2g/500g±0.1g
Ball diameter
5mm/8mm
Initial swing angle
6º/12º
End point swing angle
3º/4º
Oscillation period
1.4s/1s
Glass swing time
250±10s/430±10s
counting function
automatic
Size
400*400*775mm
