Overview
AMITTARI HAG-2000 glossmeter is a professional measurement of surface Gloss and fog shadow opticalin strument. Gloss (GLOSS) measurement of the percentage of reflected light, reflection fog (HAZE) detection of microstructure due to poor dispersion of pigment emulsion Appearance.
Features
1. Suitable for floor maintenance, surface cleaning and other surface Gloss measurement
2. Support gloss measurement of stones, tiles, paint and other materials
3. Can measure paints, inks, paints protective layer, wax film and car body paints and other surfaces
4. Gloss measurement for plastic, paper and Miscellaneous Non-metallic materials
5. Glossiness values of 20 °, 60 ° and 85 ° angle measurement can be displayed at the same time
Equipped with 56 sets of numerical memory functions
7. Portable design, weight about 310g, easy to use on site
Principle
The instrument evaluates Glossiness (GLOSS) by measuring the percentage of the amount of light reflected from the surface, while detecting the emulsion Appearance effect due to microstructure to evaluate Haze (HAZE). Multi-angle projection (20 °, 60 ° and 85 °) ensures measurement accuracy.
Applications
Floor care, surface cleaning, stones, tiles, paint sprays, paints, inks, paints, wax films, car body paints, plastics, paper, Miscellaneous Non-metallic materials
Standards
ASTMD523、ASTMD1455、ASTMC346、ASTMC584、ASTMD2457、ISO2813、DIN67530、ENISO7668、JISZ8741、MFT30064、TAPPIT480、GB9754、GB/T13891、GB7706、GB8807、JJG 696-2002
Steps
1. Turn on the instrument power
Select the appropriate Measurement Angles (20 °, 60 ° or 85 °)
3. Align the instrument measurement head to the surface to be measured
4. Press the measurement button for data collection
5. Read and record Glossiness and Shadow values
Up to 56 sets of measurement data can be stored
7. Turn off the power after use
Notice
• Ensure Ambient Temperature Range of 0~ 40 ° C
• relative humidity not more than 85%
• Check the battery level before use, the power supply is 2 * 1.5AAA battery
• Keep the instrument stable during measurement and avoid shaking
Periodically calibrate instruments to ensure measurement accuracy
• Avoid use in strong magnetic fields or vibration environments
• Use a soft fabric when cleaning the measurement head to avoid scratches
