AMITTARI AT-180S Acoustic belt tension Tester adjustable Probe storage 20 sets of paraMeters

Name: AMITTARI AT-180S Acoustic belt tension Tester adjustable Probe storage 20 sets of paraMeters
Brand: AMITTARI
SKU: NB047766
Price: 355.0 USD
Availability: InStock

$ 355.00Ex works

Measurement frequency up to 680Hz with accuracy in the range of +/- 1Hz to +/- 1%, suitable for transmission system vibration detection.

Model

AT-180S

Get Quote

Category : Tensiometer

Brand : AMITTARI

SKU : NB047766

Service :The delivery and service By NBCLab.Com

Overview

The AMITTARI AT-180S Acoustic Belt tension Tester is used for measurement of Frequency of belt vibration in Hertz (Hz) upon impact or rapid movement.

Features

1. Adjustable Probe 2. Can store 20 set belt parameters 3. Maximum Frequency: 680 Hz 4. Automatic shutdown

Principle

The belt tension is assessed by measurement of Frequency of belt vibration on impact or rapid movement.

Steps

1. Probe 2. Set belt parameters 3. Carry out measurements 4. The equipment automatically shuts down

Notice

- Temperature range + 10 ° C to + 50 ° C - Transport Temperature range -5 ° C to + 70 ° C - Uses 4 1.5V AAA batteries as power supply

Measurement Range
10HZ-680HZ
Free section belt length
Max 9999mm
Belt width
Max 999.9mm/R
Belt mass
Max 999.9 g/m
accuracy
±1HZ<100hz and=
Digital sampling error
< 1%
Temperature Range
-5 to +70℃
show
LCD
Measurement unit
Hz/N
power supply
4*1.5V AAA
shell
Plastic (ABS)
Packaging Dimensions
248*206*52mm
standard accessories
Host (one)
