SHIBO BZT non-stick tire time Tester road marking paints drying time Tester

Name: SHIBO BZT non-stick tire time Tester road marking paints drying time Tester
Brand: SHIBO
SKU: NB048318
Price: 229.0 USD
Availability: InStock

$ 229.00Ex works

The instrument uses 241 +/- 6mm tire uniform rolling detection, wet film thickness 200um +/- 20um, every 30 seconds, repeability test, accurate determination of non-stick tire drying time, suitable for marking Coating quality control.

Model

Get Quote

Category : Drying Tester

Brand : SHIBO

SKU : NB048318

Service :The delivery and service By NBCLab.Com

Overview

SHIBO BZT non-stick tire time tester is mainly used for the determination of non-stick tire drying time of room temperature marking Coatings and heating marking Coatings in GA/T298-2001 "road marking paints". The instrument meets the relevant standards and is suitable for the quality control of road marking paints.

Features

1. Dedicated to road marking paints non-stick tire drying time determination; 2. Comply with GA/T298-2001 standard; 3. The tire size is 241 +/- 6mm, with high accuracy; 4. The instrument weight is 15.8 +/- 0.2kg, which is easy to operate.

Principle

By forming a wet paint film on the Glass sheet with the sample Spreader, the tire was rolled on the test plate using the measuring instrument to observe whether the tire was painted.

Applications

Road marking paints

Standards

GA/T298-2001

Steps

Spreader the sample onto a Glass sheet (200mm × 150mm × 5mm) and paint it into an 80mm wide strip parallel to the short side of the Glass sheet at the center of the long side, with a wet paint film thickness of 200um +/- 20um; 2. After coating, press the stopwatch immediately. After 10 minutes, the two handheld tester handles will roll the tester from the center of one end of the short side of the test plate at a constant speed to the other end for 1s. Immediately observe with the naked eye whether the tire of the tester has sticky paint. If there is sticky paint, immediately wipe the tire with a cotton cloth wetted with acetone or methyl ethyl ketone. After that, the repeability test is once every 30s until the tire does not stick paint. Stop the stopwatch timing, which is the "non-sticky time" of the sample.

Notice

• Spreader sample to ensure that the thickness of the moisturizing film is 200um +/- 20um; • The rolling meter needs to be operated at a constant speed, and the time is controlled within 1 second; • If the tire sticks to paint, wipe it with a cotton cloth wetted with acetone or methyl ethyl ketone immediately; • The repeability test is carried out every 30 seconds until the tire is not painted; • Pay attention to safety during operation and avoid contact with chemical solvents.

execution standard
GA/T298-2001
Tire Size
Ф241±6mm
instrument weight
15.8±0.2kg

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
