Overview
HuiNuo KTQ series adjustable Film Applicator is a new generation of drawdown blade detachable Film Applicator. It adopts magnetic suction drawdown blade design to solve the difficult cleaning problem of high viscosity and easy curing material scraping. The series provides a variety of application widths from 50mm to 600mm to meet the needs of different application scenarios.
Features
1, magnetic detachable drawdown blade structure, cleaning more convenient
2. Precise thickness adjustment with Qingliang differential head (scale and digital display optional)
3. Hardness die steel material of drawdown blade, hard aluminum oxide frame, lightweight and wear-resistant and corrosion-resistant
4, film thickness range 0~ 5000μm adjustable
5, drawdown blade accuracy +/- 2μm to 5μm (depending on the specific model)
6. Provide a variety of application widths of 50-600mm and support customization
Principle
The device is based on the principle of differential gap scraping, and a wet-film is formed by scraping on the substrate with an adjustable drawdown blade, and the magnetic attraction design is easy to disassemble and clean.
Applications
Coatings, inks R & D and Quality control, Lithium battery Electrode prepative, Optical inspection Film Spreader, Adhesive testing, Nanomaterials research
Steps
1. Install removable drawdown blades
2. Adjust the differential head to the required thickness
3. Perform scraping operation
4, remove drawdown blade for cleaning
Notice
• Drawdown blade accuracy varies by model, not virtual standard
• Clean the drawdown blade in time after use to prevent material curing
• Ensure the substrate is flat for uniform film
