Factory direct sales LS195 Glossmeter 60 ° Measurement Angles 0~ 200GU Measurement range

Name: Factory direct sales LS195 Glossmeter 60 ° Measurement Angles 0~ 200GU Measurement range
Brand: LinShang
SKU: NB048614
Price: 205.0 USD
Availability: InStock

$ 205.00Ex works

Adopt 60 ° standard Measurement Angles, Measurement range 0~ 200GU, Repeatability +/- 0.2GU, support USB Type-C charging, suitable for a variety of surface Gloss detection.

Model

LS195

Get Quote

Category : Gloss Meter

Brand : LinShang

SKU : NB048614

Service :The delivery and service By NBCLab.Com

Overview

The LS195 glossmeter is a factory-sold precision measuring instrument, using 60 ° standard Measurement Angles, Measurement range is 0~ 200GU, suitable for all kinds of surface Glossiness detection. The instrument adopts an engineering plastic body, equipped with USB (Type-C) charging interface and USB Interface, supports Simplified Chinese and English system languages, and Operating temperature range is 10~ 45 ℃.

Features

1. Adopt 60 ° Standard Measurement Angles, in line with international standards 2. Measurement range 0~ 200GU, covering common Glossiness detection requirements 3. High Accuracy measurement, Graduation 0.1GU 4. Repeatability and reproducibility performance 5. Equipped with rechargeable lithium battery, strong battery life 6. Support USB (Type-C) charging and data transmission 7. Dual language system support (Simplified Chinese, English) 8. Engineering plastic body, light and durable

Principle

Based on the principle of ray of light reflection, the glossmeter projects rays of light to the measured surface at a standard angle of 60 °, and calculates the Glossiness value by measuring the intensity of the reflected rays of light on the surface. The internal photoelectric Sensor of the instrument receives the reflected light signal and displays the corresponding GU value after analysis by the processing system.

Applications

Coatings, paints, plastic, metal, paper, ceramics, Stone and other surface gloss measurement

Standards

ISO 2813、ASTM D523、GB/T 9754

Steps

1. Power on and select the system language 2. Instrument calibrating 3. Align the measurement port with the measured surface 4. Press the measurement button to test 5. Read and record measurement results 6. Export data via USB interface

Notice

• Ensure that the tested surface is clean and drying Instrument must be calibrated before testing • Keep the instrument stable during measurement • Avoid use in Humidity environments • Regular charging to ensure battery performance • Pay attention to moisture and dust when storing • Measuring Area size is 9 * 15mm, the minimum size of the test object is 20mm * 10mm

Measurement Angles
60°
Measurement Range
0~200GU
Measuring Area
9*15mm
minimum Size of test object
20*10mm
Body material
Engineering Plastics
Graduation
0.1 GU
Repeatability
0~ 100GU: +/- 0.2GU/100~ 2000GU: +/- 0.2% reading
reproducibility
0~ 100GU: +/- 0.5GU/100~ 2000GU: +/- 0.5% reading
Zero value error
0.1 GU
Indication Error
0~ 100GU: +/- 1.5GU/100~ 2000GU: +/- 1.5% reading
Power supply method
Rechargeable lithium battery
system language
Simplified Chinese, English
Charging port
USB(Type-C)
Interface
USB
Operating temperature Range
10~ 45 ℃, 0~ 85% RH (no condensation)
Temperature Range
-10~ 60℃, 0~ 85% RH (no condensation)
