Yingjia 12Ac-6 Spin Coater Touchscreen 12 sets of programs automatic speed correction

Name: Yingjia 12Ac-6 Spin Coater Touchscreen 12 sets of programs automatic speed correction
Brand: YINGJIA
SKU: NB049321
Price: 2304.0 USD
Availability: InStock

$ 2304.00Ex works

Support 100-5000 rpm safe speed limit and 0.1 second time resolution, equipped with 12 sets of programs and automatic speed correction function, compact structure only 14KG, with vacuum interface compatible with a variety of experimental requirements.

Model

12Ac-6

Get Quote

Category : Spin Coater

Brand : YINGJIA

SKU : NB049321

Service :The delivery and service By NBCLab.Com

Overview

Yingjia 12Ac-6 Touchscreen spin Coater is a high-performance laboratory spin coating equipment, supporting 100-5000 rpm safe speed limit and 0.1 second time resolution to ensure accurate and stable homogenization; equipped with up to 12 sets of programs, convenient for multi-scene applications; with automatic Rotation speed correction function, easy and efficient operation; equipment compact structure, weight only 14KG, with vacuum interface, compatible with a variety of experimental needs, suitable for scientific research experiments and precision manufacturing field.

Features

1. Support 100-5000 rpm safe speed limit 2.0.1 second time resolution 3. Equipped with up to 12 sets of programs 4. Rotation speed correction function 5. Compact structure, weight only 14KG 6. Comes with a vacuum interface, compatible with a variety of experimental requirements

Principle

Rotation speed can be corrected automatically by A/K selection Kx practice run to ensure the accuracy and stability of the homogenization process.

Applications

Scientific research experiments, precision manufacturing

Steps

1. Select Kx practice run via A/K 2. Rotation speed correction 3. Go back to Kx to use 4. Set homogenizing time and Rotation speed parameters according to requirements

homogenizing time
3000S, resolution 0.1S
speed Range
Contact customer service to confirm
speed correction
Rotation speed can be automatically corrected by selecting Kx practice run through A/K, and then go back to Kx to use
Acceleration
Depending on the model and purpose, no such function or 100-3000RPM/S Range, resolution 1RPM/S
Vacuum interface
Comes with an outer diameter of 6mmPU tube 1 meter
Vacuum input requirements
0.06-0. 09MPa, Vacuum Flow rate 40-100L/min Depends on the model and application
loading diameter
Contact customer service to confirm
program group
Segments 1-5 (edit pages), 12 groups
Power Supply
AC200-230V, single phase, 200W
weight
Spin coater 14kg, optional vacuum pump 5kg
Dimension
250Mm (W) x300mm (D) x230mm (H) Height without pot

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
