Overview
Electronic Balance is a High Accuracy weighing device with a Capacity of 320g and readability accuracy of 0.1mg. It uses a new generation of electromagnetic force Sensor and OLED backlit display, supports a variety of weighing units and interfaces, and is suitable for precision weighing occasions such as laboratories.
Features
1. New Generation High Accuracy, High Resolution Electromagnetic Force Sensor, Providing Stable and Reliable Weighing Results
2. Ultra-clear OLED backlight stretchable LCD screen, supports operation with laboratory gloves
3. External calibrating function
4. A variety of weighing units: mg/g/ct/oz, etc., can be customized
5. Draft Shield eliminates static electricity design to ensure weighing accuracy
6. Lower hook design to meet special application requirements
7. Standard RS232 and USB interface, optional PC-STWC function to transfer data directly to Excel
8. Built-in date and time display function to meet traceability and compliance requirements
9. Built-in dual systems to ensure normal use in emergencies
10. Power supply: 110V-240V, 50Hz/60Hz
Principle
Using Electromagnetic Force Sensor technology, High Accuracy Weighing is achieved through the principle of electromagnetic force equilibrating. When the item is placed on the pan, the Sensor generates the corresponding electromagnetic force to equilibrate the item weight, and accurately measure and display the weight value through the electronic system.
Applications
Laboratories, scientific research institutions, pharmaceutical industry, chemical industry, jewelry appraisal, educational institutions
Steps
1. Place Balance on a Stable Workbench
2. Connect Power Adapter to 110V-240V Power Supply
3. Turn on and warm up to a stable state
4. Select the weighing unit as required
5. Place the item to be weighed in the center of the pan
6. Read the weight value on the display
7. Use peel function for net weight measurement
8. Data can be output via RS232 or USB interface
Notice
Balance in a smooth, vibration-free environment before use
• Avoid use in strong electromagnetic interference environments
• Make sure the Draft Shield is closed when weighing to avoid airflow
Periodically calibrated to ensure accuracy
• Wipe with a soft cloth when cleaning to avoid liquids from entering the inside of the device
• Power Adapter Input Voltage Range 110V-240V
• Operating temperature range is 10 ℃ -30 ℃
• Avoid Capacity 320g
