Overview
JY10002 One Percent Electronic Balance is an intelligent Balance composed of high stability Sensor and single-chip microunit of Shangtian Jingyi brand, which solves the creep and linearity problems of resistance strain Sensor. The Balance has functions such as de-tare weight, self-calibration, memory, counting, fault display, etc., accurate weighing, fast and stable, simple operation and complete functions. It is suitable for rapid measurement of object mass and quantity in industrial, agricultural, commercial, school, scientific research and other units.
Features
1. A New Generation of High Accuracy Sensors, Providing Stable and Reliable Weighing Results
2. Backlit high definition LCD LCD display, weighing results are clearly displayed
3.The pan is made of stainless steel 304, which is easy to clean and durable
4. Automatic fault detection, overload protection
5. Various weighing units g/kg/ct/oz, etc
6. Power supply: 110V-240V, 50Hz/60Hz
7. Built-in rechargeable battery, supports long-term uninterrupted use (except JY50002 and JY1003-JY5003)
8. Standard RS232 interface, optional PC-STWC function to transfer weighing data directly to open applications such as Excel (JY1003-JY5003)
9. Optional functions: dynamic weighing, USB storage, battery, printer, second display screen, lower hook, weight check alarm light, etc. (JY1003-JY5003)
Principle
JY10002 Electronic Balance adopts an intelligent system composed of a high stability Sensor and a single-chip microunit. The weighted signal is detected by the Sensor, processed by the microprocessor and the result is displayed, which solves the creep and linearity problems caused by the traditional resistance strain Sensor.
Applications
Industry, agriculture, commerce, schools, scientific research
Steps
1. Connect the Power Adapter or use the built-in battery
2. Turn it on for self-test and wait for stability.
3. Place the object to be weighed in the pan
4. Read the display results, you can use functions such as peeling and counting
5. Optional connection to RS232 interface to transfer data
Notice
• The operation temperature range is 10~ 30 ℃, avoid exceeding
• Avoid overloading to prevent damage to the Sensor
• Regularly clean the stainless steel pan to keep it accurate
• Make sure the input voltage is within the range of 110-240V when using the adapter
• It is recommended to disconnect the power supply when not in use for a long time
