XINGYUN XY5000-1BJ Hydrostatic balance density tester 5100g/0.1g

Name: XINGYUN XY5000-1BJ Hydrostatic balance density tester 5100g/0.1g
Brand: XingYun
SKU: NB050689
Price: 211.0 USD
Availability: InStock

$ 211.00Ex works

High Accuracy Strain Gauge Sensor for measurement of solid density, volume and specific gravity based on Archimedes law, large stainless steel square and LED/LCD display.

Model

XY5000-1BJ

Get Quote

Category : Hydrostatic Balance

Brand : XingYun

SKU : NB050689

Service :The delivery and service By NBCLab.Com

Product Overview

The XY-1BJ Hydrostatic Balance is a high-precision weighing instrument introduced by Lucky Electronics. It utilizes a strain gauge sensor and is designed based on Archimedes' principle to measure the density, volume, and specific gravity of solids. The product combines an electronic balance with a hydrostatic device and is primarily used in fields such as highways, transportation engineering, universities, and laboratories. It is suitable for measuring the density of materials such as ores, sand, and pebbles.

Product Features

1. Suitable for density testing of samples in the highway and textile industries. 2. Features a metal base for stable structure. 3. Equipped with a large stainless steel square tray. 4. Offers options for LED digital display or wide-view LCD high-definition screen. 5. Supports full-range tare and counting functions. 6. Includes overload alarm function. 7. Optional RS232 interface or printer.

Working Principle

This product operates based on Archimedes' principle. By measuring the difference in buoyant force experienced by an object in air and when immersed in a liquid (such as water), and combining it with weight data collected by high-precision strain gauge sensors, it calculates the density, volume, and specific gravity of solids.

Application field

Highways, transportation engineering, universities, laboratories

Maximum weighing capacity
5100g
Actual Scale Interval
0.1g
Minimum weighing capacity
2g
Repeatability
±0.2g
Linear
±0.3g
Stabilization Time
≤3s
Ambient temperature
5~35°C
Weighing pan size
160*160mm
Stent size
Length 40.5cm * Width 37cm * Height 43.5cm
Barrel size
Bucket Φ29cm, bucket height 31cm
Basket size
Mesh basket Φ14.7cm, height 15cm
Package dimensions
485*340*350mm
Gross weight
6kg
