Overview
SG-100KC large size Dial Force Gauge is a simple thrust and tension test instrument produced by SUNDOO, which has the characteristics of large test load, high accuracy and easy operation. The maximum Measured value of this product is 100KN, using Dial display, load Graduation is 0.5KN, Indication Error is +/- 2% FS, weight is about 1.3kg, and the load direction is pressure.
Features
1. Adopt dual-pointer design with peak holding and continuous load indication functions
2. External tolerance indicator, convenient for force value judgment
3. Newton and kilogram units are displayed at the same time, no unit conversion is required (units can be customized)
4. Suitable for Digital Display Force Gauge not suitable for electromagnetic interference occasions
5, Appearance structural design with patent number ZL 200930096196 and ZL 200920078157
Principle
The Force Gauge converts thrust or tension into pointer indication through a mechanical structure. The dual-pointer design can display both peak and continuous load values, and the external tolerance indicator assists in judging the range of values.
Notice
• Individuals or units using SG large-size Dial Force Gauge should establish corresponding safety systems and procedures to better and safer use of SG large-size Dial Force Gauge
• Choose the appropriate SG large size Dial Force Gauge according to the form and size of the test load
• Prohibit overload use to avoid unforeseen dangers during testing
• SG large size Dial Force Gauge is only used for relevant mechanical testing, do not use it for other purposes
• Test accuracy deviation, please contact the manufacturer or distributor for repair and calibrating
• Prohibit self-disassembly and repair to avoid greater damage or even scrap
• SG Large Size Dial Force Gauge should be calibrated according to JJG455-2000, and its cycle should not exceed one year
• When using, attention should be paid to the direction of force, which should always be consistent with the center of the indenter
