Overview
D2004W digital powerbasic stirrer is driven by brushless DC motor, which has the characteristics of no spark, high efficiency, large torque, and extremely small temperature rise of the motor. Rotation speed is digitally displayed.
Features
1. Driven by brushless DC motor, no spark, high efficiency and high torque
2. Motor temperature rise is extremely small
3. Rotation speed digital display
Principle
The stirringrod swirl/spin is driven by a brushless DC motor to realize the stirring function. Rotation speed can be adjusted by knob and displayed on the digital screen.
Steps
1. Installation: Load the column into the base and tighten it, tighten the screws, install the cross section on the column, and insert the main engine crossbar into the cross section to fix it
2. Install the stirringrod before use. The stirringrod can be directly loaded into the chuck for clamping, but to ensure the straightness of the stirringrod, there are soft connecting shafts available to connect the stirringrod.
3. Before starting the machine, put the power switch in the off position, adjust the knob counterclockwise to the minimum, then plug in the power supply, turn on the power switch, the switch built-in indicator light is on, Rotation speed is displayed as "0000", slowly adjust the knob clockwise to the required Rotation speed
Notice
• When using Stirrer, it should be accelerated slowly from slow to fast. If the straightness of the stirringrod is poor, the Rotation speed cannot be fast or the soft connecting shaft is adopted and fixed with a support sleeve in the middle.
• D2004W digital display powerbasic stirrer, please do not get too close when working, so as to avoid the danger of clothes, hair being involved and so on
• Prevent liquid from splashing when stirring
