Overview
HUITAI DHG-9240A blast drying oven is a drying equipment for industrial and mining enterprises, laboratories, R & D institutions, etc., suitable for drying, baking wax melting, sterilizing and other purposes.
Features
1. Large-screen LCD display, one-screen display of multiple sets of data, menu-type Operating interface, easy to understand and easy to operate (standard)
2. Control mode of fan speed is adopted to improve the Temperature uniformity of the studio
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box without manual adjustment
4. Adopt microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, accurate and reliable temperature control
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient
6. Cold rolled steel plate, electrostatic spray on the surface
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional)
8. With RS485 interface, the recorder and computer can be connected, and the change of temperature parameters can be recorded (optional).
Principle
Control mode and self-developed air duct circulation system to achieve uniform distribution of temperature in the studio, and automatically discharge the water vapor inside the box. Microcomputer temperature controller precisely controls the temperature to ensure the Stability and Reliability of the drying process.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
1. Connect the power supply (AC 220V 50Hz)
2. Set the required temperature (Temperature range RT + 10~ 250 ℃)
3. Set the timing time (1~ 9999min)
4. Start the equipment for drying, baking or sterilizing operations
5. Monitor temperature parameter changes (recorder and computer can be connected through RS485 interface, optional)
Notice
• Power supply voltage meets requirements before use (AC 220V 50Hz)
• Note that Temperature Fluctuation is +/- 1 ℃ to avoid use beyond the range
• Regularly clean the liner, using a semi-circular four-corner design for easy maintenance
• If an independent temperature limit alarm system is selected, ensure its normal operation to ensure safety
• Avoid operating above the limit temperature to prevent automatic interruption of the equipment
• Pay attention to safety when loading and unloading the shelf bracket to prevent scratches
