Overview
HUITAI BPG-9070A precision blast drying oven is a equipment suitable for industrial and mining enterprises, laboratories, R & D institutions and other places, mainly used for drying, baking wax melting and sterilizing operations.
Features
1. Large-screen LCD display, one-screen display of multiple sets of data, menu-type Operating interface, easy to understand and easy to operate.
2. Control mode of fan speed is adopted to improve the Temperature uniformity of the studio.
3. Adopt the self-developed air duct circulation system to automatically discharge the water vapor inside the box.
4, with over-temperature deviation protection, digital display microcomputer temperature controller, with timing function, accurate and reliable temperature control.
5. The liner is made of mirror stainless steel, the shelf bracket can be freely loaded and unloaded, and the semi-circular four-corner design makes cleaning more convenient.
6. Cold rolled steel plate is used for the casing of the box, and the surface is electrostatic sprayed.
7. Independent temperature limit alarm system, which automatically interrupts when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents. (optional)
8. With RS485 interface, it can be connected to a recorder and a computer, capable of recording changes in temperature parameters. (optional)
Principle
The equipment realizes the uniform distribution of the temperature in the studio and automatically discharges water vapor through the fast and slow control of the fan and the self-developed air duct circulation system. The microcomputer temperature controller precisely adjusts the temperature to ensure the thermostatic operation.
Applications
Industrial and mining enterprises, laboratories, R & D institutions
Steps
Connect the power supply and ensure that the voltage is AC 220V 50Hz.
2. Set temperature, timing and other parameters through large-screen LCD display and menu Operating interface.
3. Start the equipment, and the fan and air duct circulation system will work automatically.
4. Monitor temperature changes, and the device automatically controls and records data (e.g. optional RS485 interface).
5. Turn off the power after use and clean the liner and shelf.
Notice
• Power supply voltage check before use meets AC 220V 50Hz requirements.
• Temperature range RT + 10~ 300 ℃ when setting temperature.
• Regularly clean liners and shelves to maintain equipment hygiene.
• If an independent temperature limit alarm system is selected, pay attention to monitoring the overtemperature situation.
• Avoid use in humid or flammable environments to prevent accidents.
