| Product Name | Labo LB-T541 Z Tensile Strength Tester | Horizon DLS-Z Paper tensile testing machine (horizontal) |
| Product Price | In coming | $2362.00 |
| Details | Details | |
| Model comparison | ||
| type | vertical | horizontal |
| Force range | ≤1000N | ≤1000N |
| Parameter comparison | ||
| Measurement Range | 10~1000kPa | 0~1000N |
| Indication resolution | 0.1kPa | |
| Indication Error | ±1% | |
| Indication variability | ≤1% | |
| test area | 645 +/- 10 square millimeters | |
| Parallel error in the longest horizontal direction on the surface of the test disc | ≤ 0.0005mm/square millimeter | |
| stretching speed | 1~220mm/min | 1~ 399mm/min (digitally adjustable) |
| Adhesive pressure setting Range | 99~ 1999N adjustable | |
| Pressurization time setting Range | Adjustable from 1 to 200 seconds | |
| power supply | AC 220V +/- 22V 50Hz 0.5A should be reliably grounded | AC 220V±10% 50HZ |
| Dimension | 335*325*515mm | |
| Net weight | 33kg | |
| Chinese measurement and control LCD screen service life | About 50,000 hours | |
