Overview
CNSHP DC3010 Digital Display Low Temperature Circulating Bath adopts single-chip microprocessing control, self-tuning PID adjustment, imported High Accuracy Platinum Resistance (Pt100) temperature measurement, high temperature control accuracy and low Fluctuation. The Compressor with good fully enclosed technology has high cooling efficiency, low noise, stable and reliable instrument operation, convenient and safe operation. Suitable for internal and external temperature control applications, the sample can be placed directly in the open bath thermostatic, or externally controlled Measurement unit that requires thermostatic.
Features
1. Adopt microcomputer temperature control PID adjustment, self-tuning control technology, temperature control accuracy up to +/- 0.05 ℃
2. Fully enclosed brand Compressor refrigeration system, no CFC, fast cooling
3. Temperature range can be -50~ 100 ℃, medium according to Temperature range, pure water, ethylene glycol, alcohol, etc., support customization
4. Capacity range optional 6L, 10L, 15L, 20L, 30L, support customization
5. The fuselage shell adopts anti-aging electrostatic spraying technology, and the platen liner mixing pump is made of good SUS304 stainless steel material, which is excellent in workmanship
6. Humanized R rounded corner design structure to avoid operators being injured by edges and corners
7. Removable ventilation grille, easy to clean refrigeration unit condenser
8. The domestic circulation function adopts a non-heat centrifugal circulation pump to avoid the traditional water pump from affecting the temperature field of the tank due to its own heat production
9. The external circulation function can be circulated through the external circulation of thermostatic liquid to establish a second temperature field
10. Safety protection device includes power-off protection, upper and lower limit temperature setting, temperature loss protection and alarm, low water level anti-dry burning and explosion-proof heating device, Compressor overheating and overcurrent multiple protection, Sensor open circuit display function
Principle
The Low Temperature Circulating Bath achieves accurate temperature control through single-chip microprocessing control, self-tuning PID adjustment and imported High Accuracy Platinum Resistance (Pt100) temperature measurement. The fully enclosed Compressor refrigeration system combined with professional circulation stirring design ensures that the liquid in the tank is evenly dispersed and smooth in the internal circulation, and the heat exchange is smooth. The domestic circulation adopts a heat-free centrifugal circulation pump to avoid its own heat production affecting the temperature field; the external circulation can establish a second temperature field.
Applications
Bioengineering, food, chemical industry, metallurgy, chemical analysis, petroleum, Sensor detection, thermostatic biochemical reaction, thermostatic material aging, Rotary evaporator, Abbe refractometer, Viscometer, Rheometer, Polarimeter, atomic absorption, ICP-MS, ICP, nuclear magnetic resonance, CCD, biological fermentation tank, chemical reactor (synthesizer), electron microscope, X-Rays diffraction, X-fluorescence, vacuum sputtering Eletroplating, vacuum coating machine, ICP etching, various semiconductor equipment, fatigue testing machine, chemical deposition system, atomic deposition system, superconducting magnetic resonance, linear accelerator, CT, low magnetic resonance, X-ray machine, microwave therapy machine, medical cold cap Cooling blankets, lasers, magnetic fields, various molecular pumps, diffusion pumps, ion pumps
Notice
• Power supply voltage meets 220VAC +/- 10%, 50Hz requirements before use
Temperature range according to select the appropriate medium (such as pure water, ethylene glycol, alcohol)
• Regularly clean the removable ventilation grille to keep the refrigeration unit condenser unobstructed
• Pay attention to low water level protection to avoid dry burning of heating device
• Avoid contact with high or low temperature surfaces during operation to prevent burns or frostbite
• Ensure Sensor connection is normal to avoid open circuit affecting temperature control accuracy
• Pay attention to safety when moving, 20L and above series and models below -40 ° C use heavy-duty self-locking casters, and use folding handles on both sides when handling
