Overview
LEEB leeb810A Shore Shore Durometer is a type A Shore Shore Durometer. Measurement range is 0~ 100HA. It is a hardness gauge that integrates measurement device and data processing. It can be used with hardness testing table to achieve higher Measurement accuracy. The product has the characteristics of compact structure, accurate measurement value, easy to carry, beautiful appearance, light weight and simple operation. The measurement resolution is 0.1HA and can be connected to computer operation data.
Features
1. Can be connected to a communication cable for data transmission and communication with the computer, facilitating data management
2. With MAX Maximum latch, average automatic computer undervoltage alarm function
3. With automatic shutdown function, saving power
4. Hardness measurement with higher accuracy after connection with Shore hardness testing table
Principle
The product is a type A Shore Shore Durometer, through the measurement device for material hardness testing, and data processing integrated in one, with hardness testing table can achieve higher accuracy measurement.
Applications
Hardness measurement of plastics (such as films, appliances, etc.), synthetic rubber (such as seals, tires, rollers, hoses/belts, Wires and cables, shock absorbers, etc.) and other related chemical products
Steps
1. Turn on the hardness gauge power supply
2. Place the probe on the surface of the material to be tested
3. Read Hardness Measured value
4. Can be connected to a computer for data transmission
5. Turn off the power after use or wait for automatic shutdown
Notice
• Ambient Temperature 0~ 40 ℃
• Powered by a 3 × 1.55V button battery
• The measurement error is ≤ +/- 1HA in the range of 20-90HA
• Optional hardness gauge and RS232 communication cable
