Overview
RDS 17 #3/8\ "scraping ink bar is a stainless steel inks coating bar imported from the United States, which can be prepared with a thickness of 38.9 μm wet-film, made of imported stainless steel, the diameter of the main rod is 9.5mm. It is suitable for Coating, inks, paints, Resin, Gloss oil and other fields to prepare specific film thickness wet-film.
Features
1. Stainless steel imported from the United States
2. Wet-film with a thickness of 38.9μm can be prepared
3. Wire-wound production process
4. Main rod diameter 9.5mm, total length 400mm, application width 300mm
Principle
The scraper bar is designed by wire-wound, using stainless steel wire to form a specific height of the projection on the surface of the rod body. When scraping on the surface of the substrate, the wet film thickness can be precisely controlled to be 38.9 μm.
Applications
Coatings, inks, paints, Resins, Gloss oil
Specifications
Production process: wire-wound, wet film thickness: 38.9μm, diameter: 9.52mm, total length: 400mm, wire diameter: 0.43mm, application width: 300mm, hand width: 50mm, material: stainless steel
