Overview
HBO HW100 Portable Thermohygrometer is a digital display Thermohygrometer that integrates temperature testing and Humidity testing. It uses a high-performance capacitive polymer film Humidity Sensor and a semiconductor temperature sensor. It has the characteristics of high measurement accuracy, high resolution and multiple functions. It uses an LCD screen with white backlight function and can freely switch between Celsius and Fahrenheit test units.
Features
1. High Accuracy, High resolution, High Stability
2. point array LCD, white backlight screen
3. Two units, ° C and ° F can be switched freely, and will be automatically remembered after shutdown
4. Three temperatures, wet-bulb temperature, dewpoint temperature, dry bulb temperature (Ambient Temperature) freely switch between, automatic memory after shutdown
5. Min Max Record (MIN Minimum MAX Maximum Record)
6. Automatic shutdown APO function without operation (10 minutes)
7. Data is manually saved and invoked
8. Store 99 test data and automatically calculate the average, MAX Maximum and MIN Minimum of the stored data
9. USB connection function, rechargeable, communication
Principle
The HW100 Portable Thermohygrometer uses an external semiconductor temperature sensor and an electronic capacitive polymer thin film Humidity Sensor for measurement, which can monitor the environment temperature and Humidity parameters in real time, and display the measurement results digitally.
Applications
Thermal comfort studies, assessment of indoor air quality, verification of the operation of HVAC systems in buildings, maintenance of heating and cooling systems, monitoring of the operation of air conditioning systems during product production
Steps
1. Press the power button to turn on the device and enter the measurement interface
2. Use the HOLD key to turn data retention on/off
3. Short press the MAX/MIN key to open the MIN Minimum, MAX Maximum, and Average records, and long press to exit to real-time.
4. Use test mode for measurement
5. Press the LIGHT button to turn on/off the backlight.
6. Press the RECALL key to read the saved data
7. Short press WB/DP key to switch wet-bulb temperature, dewpoint temperature, dry bulb temperature, long press to switch ° C/° F
8. Press the SAVE key to save the current data
Notice
• Operating temperature -20 to 60 ° C, Humidity 0 to 55 ° C
Storage environment relative humidity below 80% -20 to 60 ℃ (need to remove the battery)
• Response Time up to 30 seconds
• Automatic shutdown after 10 minutes without operation
• Powered by built-in lithium battery, Battery life is about 200 hours
