Overview
Lab Basket Grinder (Model: MXY-C4000-40F) is an economical wet dispersion grinding equipment developed by MUXUAN brand for scientific research institutions and enterprises. The equipment can operate stably for a long time, with low noise, and can complete two production processes of dispersion and grinding at the same time, effectively reducing the fineness of medium and low viscosity materials in a short time.
Features
1. High grinding efficiency, good product fineness: Rotation speed up to 3000rpm, arc impeller drive, zirconia lever to make the grinding medium irregular movement, fineness up to 10um or less, liquid-liquid dispersion up to sub-micron or even nano level; separation plate whole material CNC processing, long life without clogging.
2. Easy to operate, easy to clean: its own inverter controls start-stop and speed regulation; manual or electric lifting device is optional; relatively closed design reduces solvent volatilization; unique grinding cavity design can directly clean solvent circulation; the whole machine is made of stainless steel; can be set to grind for a long time.
3. Small temperature rise, stable product: Mixing Tank with double-decked chill down jacket and mirror polishing, running water chill down, conventional temperature rise is less than 10 ° C; can be customized multiple barrels for easy use.
4. Strong non-standard: electric lifting; explosion-proof type can be customized; SS304 or SS316L material can be selected for material contact parts; support high temperature, high voltage, flammable, explosive, corrosion and other working conditions customization.
Principle
When the laboratory electric lift basket sand mill is running, the motor drives the dial rod and dispersion disc to swirl/spin at high speed, which generates negative pressure in the ground, which prompts the material to be forcibly sucked into the grinding cavity. The material and the high-density zirconia beads continue to collide and rub, making the material particle size smaller and fineness lower.
Applications
Interior-wall latex paint, industrial paint, wood paint, various colorants, water-based oily inks, pesticide suspensions
Standards
explosion-proof
Steps
1. Start the equipment and adjust to the required Rotation speed.
2. Use the electric lifting device to adjust the position of the grinding basket.
3. Set the grinding time to stop regularly.
4. During operation, the water is cooled down to control the temperature rise.
5. After finishing the grinding, use solvent circulation to clean the equipment.
Notice
The viscosity of the material should not exceed 5000 cps (mPas).
• When used under high temperature, high voltage, flammable, explosive, corrosion and other working conditions, detailed data needs to be provided for customization.
• Regularly check the separation plate and grinding medium to ensure no blockage.
• Use solvent circulation when cleaning, pay attention to safe operation.
