Overview
The US RDS imported coating bar model 22# 3/8 is a high-quality film applicator, designed with a wire-wound coating bar that follows the traditional Mayer rod principle. It features high precision of 0.1 micrometers and reliable quality, making it widely favored in the industry. This product can prepare a wet film thickness of 50.3 micrometers, with a total length of 400 mm, a coating width of 300 mm, and is made of stainless steel.
Features
1. Designed with a wire-wound rod Coater, inheriting the traditional Mayer rod principle.
2. Features high precision of 0.1 micrometers.
3. High-quality design favored by the majority of users in the industry.
4. Capable of preparing wet film thicknesses of 50.3 micrometers.
5. Made of stainless steel for strong durability.
Principle
The coating rod is based on the working principle of a wire-wound applicator, where a specific gap is formed by winding steel wire around the rod surface. As the rod moves across the substrate, the coating material passes through the gap to achieve uniform application, forming a wet film of precise thickness. Its design inherits the traditional Mayer rod coating principle, ensuring coating accuracy and consistency.
Specifications
Production process: Wire-wound, Wet film thickness: 50.3 μm, Diameter: 9.52 mm, Total length: 400 mm, Coating width: 300 mm, Handle width: 50+50 mm, Material: Stainless steel, Wire diameter: 0.56 mm
